Storage Rack Beam Roll Forming Machine Production Line
Storage Rack Beam Roll Forming Machine Production Line: Efficient and Customizable Solution for Storage Rack Beams
In the competitive world of industrial and commercial storage solutions, efficiency, precision, and strength are paramount. Our state-of-the-art Storage Rack Beam Roll Forming Machine Production Line is engineered to meet these exact demands, providing a seamless, automated, and highly customizable system for producing robust storage rack beams. This integrated line transforms raw material into finished, interlocked beams with exceptional consistency and speed, making it the ideal investment for manufacturers aiming to enhance productivity and product quality.
Workflow Diagram
The complete Storage Rack Beam Roll Forming Machine Production Line follows a meticulously designed workflow.
Uncoiling (Decoiler):
It begins with a decoiler that feeds steel coils into the system.
Roll Forming:
The material then progresses through a high-precision roll forming station, where a series of engineered rollers gradually shape the metal into the specific beam profile.
Hydraulic Cutting:
Following this, a hydraulic cutting unit cleanly shears the continuously formed beam to the required length with absolute accuracy.
Snap-lock connection roll forming machine
A key innovation of our system is the subsequent stage: the semi-finished product interlocking roll forming machine. This unique section is where two pre-formed beams are precisely crimped and locked together, forming a single, incredibly strong final beam.
Finished Product Receiving Rack:
The process concludes with an automatic stacking and receiving frame, ensuring orderly collection of the finished products without manual handling.
More parameters
| Product Name | Storage Rack Beam Roll Forming Machine Production Line |
| Main motor power | 15 kw（Siemens） |
| Hydraulic station | Vane pump, 7.5 kw |
| Produce speed | 20 m/min |
| Shaft material | 45# Steel |
| Brand of electrical control cabinet |
Phase sequence protector Independent cabinet |
| Touch screen | Siemens or customized according to customer requirements |
| Rolling materials | CCr12, hardness 55-60 (HRC), chrome plating thickness 0.01-0.015 (mm) |
| Roller diameter | 60 mm |
| Cutting blade material | Cr12MoV, hardness 58 - 62 (HRC) |
| Roller diameter | Φ75 mm |
| Voltage | 380v 50hz 3p be customized |
| Feeding thickness | 1.5 mm |
| Rows | 18-24（be customized） |
| Feeding width |
192±2 mm
|
| Product tolerance |
Length: +2 mm / all processed dimensions
Width, Height: ± 0.5 mm Other aspects: Tolerances for other dimensions (length, angles, etc.) shall conform to EN10162 cold-rolled steel profiles standard. |
| Dimensions (length × width × height) |
21 x 2 x 1.8 (meters)
|
| Weight | About 9 tons |
| Control system | PLC |
| Total power | 42 kw |
| Output material handling rack-Table length | 3m ×2 |
This Storage Rack Beam Roll Forming Machine Production Line is built for versatility and resilience. Understanding that production needs vary, we offer extensive customization. The line can be tailored to your specific requirements, including material entry width, roll forming thickness, and operating voltage, ensuring perfect compatibility with your factory's specifications and local power standards. Furthermore, to guarantee uninterrupted operation and minimal downtime, we provide comprehensive remote support. Should any technical questions arise, our engineers are available for real-time video guidance, offering expert troubleshooting and maintenance advice directly to your factory floor.
Choosing our Storage Rack Beam Roll Forming Machine Production Line means more than just purchasing machinery; it's adopting a complete production solution. It ensures dimensional accuracy, superior structural integrity of the final beam, and significant savings on labor and material costs through automated, waste-minimizing processes. From seamless roll forming to the critical interlocking phase, every component of this Storage Rack Beam Roll Forming Machine Production Line is designed for reliability and peak performance. Contact us view more...→
